The Magenta Music Server MS-01 is a network music server that combines our renowned analog technology with a precise digital circuit based on the ESS Sabre ES9038Q2M chip, capable of handling lossless decoding of PCM files up to 768KHz and DSD512.



The MS01’s analog circuitry complies with our ANA® design philosophy, allowing organic and engaging music reproduction, with wide frequency response, low distortion and accurate harmonic reproduction.



Other features of the MS-01 that make it the best choice for music lovers who want to explore the convenience of digital formats without sacrificing the recreation of crisp and clear sound images capable of conveying the intentions of the artist’s work, are its independent power supplies for the digital and analog circuits,  the use of a Shunt-type power supply for the analog filter, which is completely discrete and without the use of negative feedback, wireless or ethernet connectivity, as well as playback of digital files via network-attached storage (NAS) or USB 3.0 devices.



All this, accompanied by the operating system -with a lifetime license-, designed and finely tuned for “bit-perfect” music playback, controlled by cell phones, tablets or computers, which gives access to virtually all streaming platforms such as Tidal, Qobuz, High Res Audio, HD radio stations and many more.

TECHNOLOGY AND SPECIFICATIONS

DIGITAL TO ANALOG CONVERTER:



DAC based on the ESS Sabre ES9038Q2M chip, capable of handling lossless decoding of PCM files up to 768KHz and DSD512.

Wireless or ethernet connectivity, as well as playback of digital files via network-attached storage (NAS) or USB 3.0 devices





INPUTS:



Two 3.0 and two 2.0 USB inputs





INDEPENDENT POWER SUPPLIES:



Independent power supplies for analog and digital circuits

Shunt power supply for the analog filter





ANALOG FILTER:



Totally discrete analog filter with no negative feedback





OLED display





OUTPUTS:



2CH RCA output: 2.2Vrms/-0dB, THD+N: 0.0005% at 1KHz





CERTIFICATED COMPLIAN COMPONENTS





OS:



Lifetime licensed software designed and finely tuned exclusively for bit-perfect music playback, controlled via your mobile phone, computer or tablet.





ALIGNED NEURO-ACOUSTICS (ANA®) COMPLIANT:



The ANA® technology (Aligned Neuro-Acoustics) is one of Margules’ technological innovations developed from a fundamental principle: the human brain perceives sound by prioritizing the harmonic structure above fundamental tone; that is, it focuses on how humans perceive sound and not on how we measure it.

This technological advance originates from the engaging sound theory and is based on the way in which our brain decodes the information from the sound waves through the ears: when sounds are closer, they keep us focused due to the relation between perception and sound, the distance at which we perceive them and their intelligibility, whereas distant sounds, even when intelligible, do not catch our attention and are easily ignored.

Our ANA® technology is designed to achieve a realistic sound, with a wide frequency response, low distortion and precise harmonic reproduction, optimizing to the utmost the relationship between the source and the receiver, so that you can enjoy your music in a way you have never experienced before.





* Specifications are subject to change without notice.

PRESS

WARRANTY

Like all the Margules products, the Magenta Music Server MS-01 comes with a five-year limited warranty on parts and labor.

Terms and Conditions



The warranty does not cover any damage, wear or malfunctioning caused by lack of compliance with the operation specifications included with this equipment, or any of those resulting from:



  • Accidents, natural disasters or events that happens due to natural causes.
  • Misuse, abuse of or negligence regarding the equipment.
  • Fault in the initial set-up and installation, incorrect maintenance, and/or inadequate cleaning of the product.
  • Repairs, modifications, or renovations performed by people or companies not expressly authorized by Margules Audio.
  • Damage during shipping, transport, packaging, or manipulation of the equipment. In this case, all damage claims must be submitted to the carrier company.
  • Any other cause not attributable to a manufacturing defect of the product.



The warranty covers exclusively the expense corresponding to labor and the material necessary to the repair or, give the case, the substitution of the equipment (at the discretion of Margules Audio), and thus it does not extend to:



  • Accessories, including but not limited to: batteries, cables, mounting hardware, brackets, furniture, cleaning accessories, antennas or dismountable feeding cables.
  • Shipping costs in case the owner needs to return the unit to Margules Audio for the purpose of service or repair of a possible defect.



The warranty shall be void if:



  • The serial number of the equipment has been altered, modified, or deleted.
  • The product has been purchased from a person or company that is not an authorized distributor of Margules Audio.



This warranty extends to products directly purchased from Margules Audio or an authorized distributor.



In case of doubt regarding the scope of the warranty or if you need technical support, call the numbers you will find on our website www.margules.com.
